Triple HDMI switch SKY SAT HL-3X1 SW

   SKY SAT HL-3X1 SW is an HDMI switch that has three HDMI inputs and one HDMI output. It is designed to connect three sources with HDMI output to one HDMI compatible TV or video projector.

KIT INCLUDES:

• HDMI switch 3X1- 1 pc.
• Operating manual in Bulgarian - 1 pc.

DESCRIPTION:

• High quality HDMI dongle.
• Ability to connect several HDTV satellite receivers (or other) to 1 TV/video projector.
• Three HDMI inputs and one HDMI output.
• Easy to use.
• Installs in seconds.
• It doesn't need power
• It doesn't need any special settings.
• Supports HDMI 1.4A.
• Supports 3D.
• Supports CEC.
• Supports HDCP 1.2.
• Supports 12 bit deep color.
• Supports Blue-Ray 24/fs, 50/fs, 60/fs, HD-DVD, xvYCC.
• Supports digital audio formats such as DTS-HD, Dolby-TrueHD, LPCM7.1, DTS, Dolby-AC3, DSD.

MAIN CHARACTERISTICS:

• Video resolutions support: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p / 24fs, 50fs, 60fs.
• Audio format support: DTS-HD, Dolby-trueHD, LPCM7.1, DTS, Dolby-AC3, DSD (max. bandwidth 250 MHz).
• Maximum baud rate: 7.5 Gbps.
• Input/output TMDS signal: 0.5~1.5 Volts p-p (TTL).
• Input/output DDC signal: 5 Volts p-r (TTL)
• Maximum input cable length: up to 5 m (AWG 26 HDMI standard cable).

FRONT PANEL:

• 3 HDMI inputs.

REAR PANEL:

• 1 HDMI output.
• 3 LED indicators.
• Button to switch inputs.

PHYSICAL CHARACTERISTICS:

• Operation at temperature: -15°C~+55°C.
• Storage temperature: -20°C~+70°C.
• Weight: 0.100 Kg.
• Warranty: 2 years.
